SKU: H030-00-006

eaZIflex RONIX

This product is available on request. Please contact us via our contact form for more information.

Description

eaZIflex RONIX - Elegant hinge with soft-closing mechanism for glass doors and more

The eaZIflex RONIX is the ideal hinge for sophisticated doors that need to impress in terms of both functionality and design. With an integrated soft-close system, it ensures that the door closes gently and quietly - perfect for glass doors, but also suitable for other materials such as wood.

Advantages of the product:

  • SOFT CLOSE included: The hinge is equipped with high-quality cushioning, which ensures smooth and almost silent closing.
  • Versatile use: It was specially developed for glass doors, but can also be used for wooden or other door materials without any problems.
  • Easy to open: The door is particularly easy to open thanks to the innovative hinge - a noticeable relief in everyday use.
  • Elegant design: The minimalist and stylish design blends perfectly into modern interiors and remains unobtrusive while offering maximum functionality.

Function of the product:

  • 180° open position: The door remains stable at an opening angle of 180°, allowing the passageway to be opened and released with ease.
  • Self-closing: From an opening angle of 160°, the door closes automatically to 0° - gently and silently thanks to the built-in soft-closing mechanism.

Note:

  • Door stopper recommended: To maximise the service life of the product and prevent damage caused by excessive loads, we recommend using a door stopper.
  • Maximum load: Each hinge is designed for a load of up to 60 kg, ideal for use on medium-sized doors.

Give your doors a particularly elegant and functional solution with the eaZIflex RONIX, which is not only visually impressive, but also impresses with its user-friendliness in everyday use.

  • Medium
    Fluid
  • Technology
    Defined Comfort
  • Logo
    Zimmer
  • Lifetime
    500000 Zyklen
  • Field of application
    10 - 40 °C
  • Hinge type
    Belt hinge
  • Load capacity per hinge
    60 kg
  • Damping
    yes
  • Closure
    yes
  • Closure from
    160 °
  • Housing material
    Aluminium
  • Housing color
    black
  • Housing surface
    anodized
  • Length
    63.3 mm
  • Width
    56.5 mm
  • Height
    212.9 mm
  • Weight
    0.7903 kg
  • Diameter
    31 mm
  • Fastening type on door side
    Clampable
  • Mounting type On-site
    Screwable
  • Opening direction
    DIN R
  • Opening angle
    180 °
  • Adjustable zero position
    no
  • Door thickness
    8 - 21.5 mm
  • Type of glass
    ESG/VSG aus ESG
  • Carton, PU
    1 Stück
  • Cardboard, weight
    0.9 kg
  • Cardboard, width
    215 mm
  • Cardboard, length
    110 mm
  • Cardboard, height
    160 mm
